Lip seal for pipe connections
Seal for backwater-proof connection of the gully and extension element/scupper
Function
Leak-tested, legally compliant backwater-proof seals for connecting two different pipe diameters provide the perfect seal for connections between gullies and flat roof drains.
Material
Our lip seals are made from EPDM (ethylene propylene diene monomer rubber) and are consequently highly resistant to all weather conditions. UV and ozone-resistant with strong resilience to chemicals, temperature and footsteps, EPDM is the ideal material for a wide range of sealing tasks.
Versions
| Suitable for | External dimensions/height |
|---|---|
| Drain pipe diameter D 50 mm | 73 x 29 mm |
| Drain pipe diameter D 75 mm | 109 x 38 mm |
| Drain pipe diameter D 95 mm small | 113 x 19 mm |
| Drain pipe diameter D 95 mm large | 146 x 30 mm |
| Drain pipe diameter D 110 mm | 126 x 35 mm |
| Drain pipe diameter D 125 mm | 172 x 32 mm |
| Drain pipe diameter D 160 mm | 207 x 33 mm |
Examples
Certifications
The drainage capacity has been tested by TÜV Rheinland LGA (test performed on drain, incl. lip seal).
| Technical data | |||
|---|---|---|---|
| Lip seal version | Drain size | External dimensions/height | Suitable for |
| D 50 mm (DN 50) |
D 50 mm (DN 50) |
73 x 29 mm | D 75 mm (DN 70) |
| D 75 mm (DN 70) |
D 75 mm (DN 70) |
109 x 38 mm | D 110 mm (DN 100) |
| D 95 mm small | D 95 mm | 113 x 19 mm | D 110 mm (DN 100) |
| D 95 mm large | D 95 mm | 146 x 30 mm | D 125 mm (DN 125) |
| D 110 mm (DN 100) |
D 110 mm (DN 100) |
126 x 35 mm | D 125 mm (DN 125) |
| D 125 mm (DN 125) |
D 125 mm (DN 125) |
172 x 32 mm | D 160 mm (DN 150) |
| D 160 mm (DN 150) |
D 150 mm (DN 150) |
207 x 33 mm | D 165 mm to D 180 mm |
Downloads
Package units
Supplied in cartons & foil bags, each containing 1 unit
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
