Function
Structure part for horizontal emergency drainage through the parapets of flat roofs or terraces. Install by connecting to a pipe system for water drainage, or use for free-flow drainage. When installing the emergency overflow Classic, the precise installation point depends on the water level.
Material
Our emergency overflows Classic are available in PVC and FPO/PP for connection to the matching material used for the roof membrane. The material compounds used are low-temperature impact resistant, weatherproof and stabilized against ultraviolet rays, oxidative decomposition and thermal aging.
Nexo Fix Ausführungen
Abläufe, Notüberläufe, Speier – rund und rechteckig – sowie Lüfter mit Folienanschluss.
| Hersteller | Folientyp | Farbe | Material |
|---|---|---|---|
| Bauder | Thermofol | lichtgrau | PVC |
| Bauder | Thermoplan T | silbergrau | PP |
| Sika |
Sikaplan
|
hellgrau
|
PVC
|
| Sika |
Sarnafil T
|
beige
|
PP
|
| Soprema |
Flagon SR
|
hellgrau
|
PVC
|
| Soprema |
Flagon PREMIO
|
sandgrau
|
PP
|
Es sind verschiedene Maße von Folienanschlüssen erhältlich mit jeweils 10 cm Folienüberstand an der Flanschkante. Weitere Dachbahnen auf Anfrage.
Versions PVC
| Material | Technical information | |
|---|---|---|
| PVC similar to RAL 7035, Light grey |
With bitumen sleeve Pipe length 490 mm |
D 50 mm (DN 50) |
| D 63 mm | ||
| D 75 mm (DN 70) |
||
| D 110 mm (DN 100) |
||
| D 125 mm (DN 125) |
||
Pipe inclination 5°.
Special sizes available on request / The processing instructions of the roof sheeting manufacturer must be observed; Materials and material compounds used may be subject to change.
Versions FPO/PP
| Material | Technical information | |
|---|---|---|
| FPO/PP similar to RAL 7044, Silk grey |
With bitumen sleeve Pipe length 490 mm |
D 50 mm (DN 50) |
| D 63 mm | ||
| D 75 mm (DN 70) |
||
| D 110 mm (DN 100) |
||
| D 125 mm (DN 125) |
||
Pipe inclination 5°.
Special sizes available on request / Also available in PE (roofing membranes based on PE) / The processing instructions of the roof sheeting manufacturer must be observed; Materials and material compounds used may be subject to change.
Examples
Drainage performance litre/sec:
LGA-certified characteristics
| Technical data | ||
|---|---|---|
| Diameter | Accumulation height | |
| 35 mm | 65 mm | |
| D 50 mm (DN 50) |
0.51 | 1.31 |
| D 75 mm (DN 70) |
0.65 | 1.65 |
| D 110 mm (DN 100) |
1.00 | 2.65 |
| D 125 mm (DN 125) |
1.00 | 2.80 |
Technical drawings
| Technical data | ||
|---|---|---|
| D1 | 50 / 63 / 75 / 110 / 125 | mm |
| a | 300 | |
| l | 490 | |
| t | 3.0 | |
Downloads
Package units
Supplied in cartons, each containing 1 unit
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
Function
Structure part for horizontal emergency drainage through the parapets of flat roofs or terraces. Install by connecting to a pipe system for water drainage, or use for free-flow drainage. When installing the emergency overflow Classic, the precise installation point depends on the water level.
Material
Our emergency overflows Classic are available in PVC and FPO/PP for connection to the matching material used for the roof membrane. The material compounds used are low-temperature impact resistant, weatherproof and stabilized against ultraviolet rays, oxidative decomposition and thermal aging.
Nexo Fix Ausführungen
Abläufe, Notüberläufe, Speier – rund und rechteckig – sowie Lüfter mit Folienanschluss.
| Hersteller | Folientyp | Farbe | Material |
|---|---|---|---|
| Bauder | Thermofol | lichtgrau | PVC |
| Bauder | Thermoplan T | silbergrau | PP |
| Sika |
Sikaplan
|
hellgrau
|
PVC
|
| Sika |
Sarnafil T
|
beige
|
PP
|
| Soprema |
Flagon SR
|
hellgrau
|
PVC
|
| Soprema |
Flagon PREMIO
|
sandgrau
|
PP
|
Es sind verschiedene Maße von Folienanschlüssen erhältlich mit jeweils 10 cm Folienüberstand an der Flanschkante. Weitere Dachbahnen auf Anfrage.
Versions PVC
| Material | Technical information | |
|---|---|---|
| PVC similar to RAL 7035, Light grey |
With bitumen sleeve Pipe length 490 mm |
D 50 mm (DN 50) |
| D 63 mm | ||
| D 75 mm (DN 70) |
||
| D 110 mm (DN 100) |
||
| D 125 mm (DN 125) |
||
Pipe inclination 5°.
Special sizes available on request / The processing instructions of the roof sheeting manufacturer must be observed; Materials and material compounds used may be subject to change.
Versions FPO/PP
| Material | Technical information | |
|---|---|---|
| FPO/PP similar to RAL 7044, Silk grey |
With bitumen sleeve Pipe length 490 mm |
D 50 mm (DN 50) |
| D 63 mm | ||
| D 75 mm (DN 70) |
||
| D 110 mm (DN 100) |
||
| D 125 mm (DN 125) |
||
Pipe inclination 5°.
Special sizes available on request / Also available in PE (roofing membranes based on PE) / The processing instructions of the roof sheeting manufacturer must be observed; Materials and material compounds used may be subject to change.
Examples
Drainage performance litre/sec:
LGA-certified characteristics
| Technical data | ||
|---|---|---|
| Diameter | Accumulation height | |
| 35 mm | 65 mm | |
| D 50 mm (DN 50) |
0.51 | 1.31 |
| D 75 mm (DN 70) |
0.65 | 1.65 |
| D 110 mm (DN 100) |
1.00 | 2.65 |
| D 125 mm (DN 125) |
1.00 | 2.80 |
Technical drawings
| Technical data | ||
|---|---|---|
| D1 | 50 / 63 / 75 / 110 / 125 | mm |
| a | 300 | |
| l | 490 | |
| t | 3.0 | |
Downloads
Package units
Supplied in cartons, each containing 1 unit
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
