Vapour barrier sheet for round and rectangular scuppers and emergency overflows
Pre-configured sheet for vapour-tight routing of the pipe to the parapet
Function
It’s important that the opening for the pipe routing through the parapet is properly sealed. Simply place the vapour barrier sheet over the opening on the inside of the parapet and connect to the substrate. Then just connect the vapour barrier membrane to the tray and you’re all done! Emergency overflows can easily be slotted in during subsequent installation, whereby the lip seal of the vapour barrier sheet fits the pipe on all sides.
Material
The base is made from PVC to ensure it is resistant against weather conditions and UV radiation. PVC is low-temperature impact resistant and can consequently resist mechanical stress even at low temperatures. The seal insert is made from EPDM and offers similarly durable properties combined with excellent sealing effectiveness thanks to the high flexibility of the rubber.
Versions
Round scuppers and emergency overflows
| Material | for diameter |
|---|---|
| PVC sheet, 300 x 300 mm, similar to RAL 7047, Telegrau 4 |
D 50 mm (DN 50) |
| D 75 mm (DN 70) |
|
| D 95 mm | |
| D 110 mm (DN 100) |
|
| D 125 mm (DN 125) |
Example
Versions
Rectangular scuppers and emergency overflows
| Material | Duct = W x H x L mm |
|---|---|
| PVC sheet, similar to RAL 7047, Telegrau 4 |
for 120 x 60 |
| for 180 x 80 | |
| for 300 x 80 | |
| for 300 x 100 | |
| for 500 x 100 | |
| for 600 x 100 | |
| for 750 x 100 | |
| for 1000 x 100 |
Example
Technical drawings
Round scuppers and emergency overflows
| Technical data | |||
|---|---|---|---|
| Round scuppers and emergency overflows | |||
| Version | Width B | Height H | |
| D 50 mm (DN 50) |
300 | 300 | mm |
| D 75 mm (DN 70) |
|||
| D 95 mm | |||
| D 110 mm (DN 110) |
|||
| D 125 mm (DN 125) |
|||
Technical drawings
Rectangular scuppers and emergency overflows
| Technical data |
|||
| Rectangular scuppers and emergency overflows | |||
| Version | Width B | Height H | |
| 120 x 60 | 320 | 260 | mm |
| 180 x 80 | 380 | 280 | |
| 300 x 80 | 500 | ||
| 300 x 100 | 300 | ||
| 500 x 100 | 700 | ||
| 600 x 100 | 800 | ||
| 750 x 100 | 950 | ||
| 1000 x 100 | 1200 | ||
Downloads
Package units
Supplied in cartons, each containing 1 unit
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
Function
It’s important that the opening for the pipe routing through the parapet is properly sealed. Simply place the vapour barrier sheet over the opening on the inside of the parapet and connect to the substrate. Then just connect the vapour barrier membrane to the tray and you’re all done! Emergency overflows can easily be slotted in during subsequent installation, whereby the lip seal of the vapour barrier sheet fits the pipe on all sides.
Material
The base is made from PVC to ensure it is resistant against weather conditions and UV radiation. PVC is low-temperature impact resistant and can consequently resist mechanical stress even at low temperatures. The seal insert is made from EPDM and offers similarly durable properties combined with excellent sealing effectiveness thanks to the high flexibility of the rubber.
Versions
Round scuppers and emergency overflows
| Material | for diameter |
|---|---|
| PVC sheet, 300 x 300 mm, similar to RAL 7047, Telegrau 4 |
D 50 mm (DN 50) |
| D 75 mm (DN 70) |
|
| D 95 mm | |
| D 110 mm (DN 100) |
|
| D 125 mm (DN 125) |
Example
Versions
Rectangular scuppers and emergency overflows
| Material | Duct = W x H x L mm |
|---|---|
| PVC sheet, similar to RAL 7047, Telegrau 4 |
for 120 x 60 |
| for 180 x 80 | |
| for 300 x 80 | |
| for 300 x 100 | |
| for 500 x 100 | |
| for 600 x 100 | |
| for 750 x 100 | |
| for 1000 x 100 |
Example
Technical drawings
Round scuppers and emergency overflows
| Technical data | |||
|---|---|---|---|
| Round scuppers and emergency overflows | |||
| Version | Width B | Height H | |
| D 50 mm (DN 50) |
300 | 300 | mm |
| D 75 mm (DN 70) |
|||
| D 95 mm | |||
| D 110 mm (DN 110) |
|||
| D 125 mm (DN 125) |
|||
Technical drawings
Rectangular scuppers and emergency overflows
| Technical data |
|||
| Rectangular scuppers and emergency overflows | |||
| Version | Width B | Height H | |
| 120 x 60 | 320 | 260 | mm |
| 180 x 80 | 380 | 280 | |
| 300 x 80 | 500 | ||
| 300 x 100 | 300 | ||
| 500 x 100 | 700 | ||
| 600 x 100 | 800 | ||
| 750 x 100 | 950 | ||
| 1000 x 100 | 1200 | ||
Downloads
Package units
Supplied in cartons, each containing 1 unit
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
