Universal weather cap for flat roof fans
Prevents rainwater and animals from entering ventilation systems
Function
Weatherproof cover for ventilation ducts. Securing the ventilation duct with the KALA weather protection cap prevents snow and rain from entering. The streamlined cross-section facilitates the exchange of air.
The weather protection cap is simply pushed onto the ventilation duct and pressed tight. The guide pins are designed for connection to DN 100 and DN 125 ventilation ducts. The design provides for a secure hold of the cap on the duct.
Material
FPO/PP, impact resistant, weatherproof, UV-stabilized
Versions
| Accessory suitable for | Color | Durchmesser |
|---|---|---|
| Cold roof fans, Flat roof fans |
Gray | D 75 mm (DN 70) 1 |
| Black | D 110 mm (DN 100) | |
| D 125 mm (DN 125) | ||
| Gray | D 160 mm (DN 150) 1 |
1 Attention: Please note that the technical dimensions and visual representation may differ from the illustration
Examples
Technical drawings
| Technical data | |
|---|---|
| h | 118 mm |
| D1 | ø 180 mm |
| D2 | ø 125 mm |
| D3 | ø 110 mm |
Downloads
Package units
Supplied in foil bags, each containing 1 unit
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
