Flat roof fans for ventilation lines with weather cap
Fan for directly connecting ventilation lines through the roof system
Function
The flat roof fan for ventilation lines reliably guides exhaust air lines through the flat roof system, ensuring issue-free extraction of exhaust air from bathrooms, toilets, wastewater pipe systems, extractor hoods in the kitchen or from controlled air conditioning. Supplied complete with weather cap.
Material
Our fans are available in PVC and FPO/PP for connection to the matching material used for the roof membrane.
The material compounds used are low-temperature impact resistant, weatherproof and stabilized against ultraviolet rays, oxidative decomposition and thermal ageing.
Versions PVC
| Material | Technical information | Height |
|---|---|---|
| PVC similar to RAL 7035, Light grey |
D 75 mm (DN 70) |
654 mm pipe length above/below tray 300/320 mm |
| D 110 mm (DN 100) |
||
| D 125 mm (DN 125) |
||
| D 160 mm (DN 150) |
Special sizes available on request / The processing instructions of the roof sheeting manufacturer must be observed; Materials and material compounds used may be subject to change.
Versions FPO/PP
| Material | Technical information | Height |
|---|---|---|
| FPO/PP similar to RAL 7044, Silk grey |
D 75 mm (DN 70) |
654 mm pipe length above/below tray 300/320 mm |
| D 110 mm (DN 100) |
||
| D 125 mm (DN 125) |
||
| D 160 mm (DN 150) |
Special sizes available on request / Also available in PE (roofing membranes based on PE) / The processing instructions of the roof sheeting manufacturer must be observed; Materials and material compounds used may be subject to change.
Examples
Technical drawings
| Technical data | |
|---|---|
| H1 with cap | 654 mm |
| H2 without cap | 620 mm |
| D1 | DN 70 / DN 100 / DN 125 / DN 150 |
| D sheet D2 | For size DN 70 = 300 mm For all others = 380 mm |
| h1 with cap | 334 mm |
| h2 without cap | 300 mm |
| h | 320 mm |
Downloads
Package units
Supplied in cartons, each containing 1 unit
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
Function
The flat roof fan for ventilation lines reliably guides exhaust air lines through the flat roof system, ensuring issue-free extraction of exhaust air from bathrooms, toilets, wastewater pipe systems, extractor hoods in the kitchen or from controlled air conditioning. Supplied complete with weather cap.
Material
Our fans are available in PVC and FPO/PP for connection to the matching material used for the roof membrane.
The material compounds used are low-temperature impact resistant, weatherproof and stabilized against ultraviolet rays, oxidative decomposition and thermal ageing.
Versions PVC
| Material | Technical information | Height |
|---|---|---|
| PVC similar to RAL 7035, Light grey |
D 75 mm (DN 70) |
654 mm pipe length above/below tray 300/320 mm |
| D 110 mm (DN 100) |
||
| D 125 mm (DN 125) |
||
| D 160 mm (DN 150) |
Special sizes available on request / The processing instructions of the roof sheeting manufacturer must be observed; Materials and material compounds used may be subject to change.
Versions FPO/PP
| Material | Technical information | Height |
|---|---|---|
| FPO/PP similar to RAL 7044, Silk grey |
D 75 mm (DN 70) |
654 mm pipe length above/below tray 300/320 mm |
| D 110 mm (DN 100) |
||
| D 125 mm (DN 125) |
||
| D 160 mm (DN 150) |
Special sizes available on request / Also available in PE (roofing membranes based on PE) / The processing instructions of the roof sheeting manufacturer must be observed; Materials and material compounds used may be subject to change.
Examples
Technical drawings
| Technical data | |
|---|---|
| H1 with cap | 654 mm |
| H2 without cap | 620 mm |
| D1 | DN 70 / DN 100 / DN 125 / DN 150 |
| D sheet D2 | For size DN 70 = 300 mm For all others = 380 mm |
| h1 with cap | 334 mm |
| h2 without cap | 300 mm |
| h | 320 mm |
Downloads
Package units
Supplied in cartons, each containing 1 unit
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
