One-piece inspection fitting Nexo Fix for flat roof systems
Zuverlässig dichte, verschließbare Öffnung zur Zustandskontrolle des Dachpakets
Function
The inspection fitting is used for regular, simple and safe inspection of the flat roof without damaging openings. Leaks can therefore be discovered quickly and the extent of the damage can therefore be significantly reduced.
Material
- PVC similar to RAL 7035, Light grey
- FPO/PP similar to RAL 7044, Silk grey
Versions PVC
| Material | Technical information | Height |
|---|---|---|
| PVC similar to RAL 7035, Light grey |
D 125 mm (DN 125) |
605 mm |
Special lengths available on request.
Attention: The processing instructions of the roofing membrane manufacturer must be adhered to; Materials and used material compounds may be subject to change.
Nexo Fix versions
with bitumen sleeve (on request)
Versions FPO/PP
| Material | Technical information | Height |
|---|---|---|
| FPO/PP similar to RAL 7044, Silk grey |
D 125 mm (DN 125) |
605 mm |
Special lengths available on request.
Attention: The processing instructions of the roofing membrane manufacturer must be adhered to; Materials and used material compounds may be subject to change.
Nexo Fix versions
| Manufacturer | Foil type |
|---|---|
| Bauder | Thermoplan T |
| SIKA | Sarnafil TS77 |
| Soprema | FLAGON Premio |
Examples
Technical drawings
| Technical data | |||
|---|---|---|---|
| H | 380 | mm | |
| D pipe D1 | 125 | ||
| D sheet D2 | 380 | ||
| Foil connection (FA) | D125 | L 580 x W 580 mm | |
| The total height including the polystyrene core is 605 mm | |||
Package units
Supplied in foil bags, each containing 1 unit
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
Function
The inspection fitting is used for regular, simple and safe inspection of the flat roof without damaging openings. Leaks can therefore be discovered quickly and the extent of the damage can therefore be significantly reduced.
Material
- PVC similar to RAL 7035, Light grey
- FPO/PP similar to RAL 7044, Silk grey
Versions PVC
| Material | Technical information | Height |
|---|---|---|
| PVC similar to RAL 7035, Light grey |
D 125 mm (DN 125) |
605 mm |
Special lengths available on request.
Attention: The processing instructions of the roofing membrane manufacturer must be adhered to; Materials and used material compounds may be subject to change.
Nexo Fix versions
with bitumen sleeve (on request)
Versions FPO/PP
| Material | Technical information | Height |
|---|---|---|
| FPO/PP similar to RAL 7044, Silk grey |
D 125 mm (DN 125) |
605 mm |
Special lengths available on request.
Attention: The processing instructions of the roofing membrane manufacturer must be adhered to; Materials and used material compounds may be subject to change.
Nexo Fix versions
| Manufacturer | Foil type |
|---|---|
| Bauder | Thermoplan T |
| SIKA | Sarnafil TS77 |
| Soprema | FLAGON Premio |
Examples
Technical drawings
| Technical data | |||
|---|---|---|---|
| H | 380 | mm | |
| D pipe D1 | 125 | ||
| D sheet D2 | 380 | ||
| Foil connection (FA) | D125 | L 580 x W 580 mm | |
| The total height including the polystyrene core is 605 mm | |||
Package units
Supplied in foil bags, each containing 1 unit
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
