Gravel basket classic for drain and scupper
KALA drain attachment for reliable retention of coarse dirt particles
Function
Effectively and permanently avoid blockages in your flat roof drain system with KALA gravel basket classic for drain and scupper for universal use: Reliable retention of coarse dirt particles to prevent obstructions from accumulating in your drainage system. The LGA-certified, flow-optimised design ensures minimal loss of flow and high performance, even during torrential rain. The highly adjustable cross-shaped fastening bar permits quick and easy installation in drain pipes. All you need to do is shorten the length of the cross’ wings and press it into the pipe.
Material
Our gravel basket classic for drain and scupper is made from HDPE, a highly weatherproof, UV radiation blocking, and low-temperature impact resistance material.
Versions
| Accessory suitable for | Diameter |
|---|---|
| Drains D 50 mm (DN 50) – D 160 mm (DN 150) |
Basket D 262 mm Basket H 77.5 mm |
| Scuppers D 50 mm (DN 50) – D 125 mm (DN 125) |
Due to its easily adjustable cross-shaped installation fastening bar, the gravel basket classic for drain and scupper is suitable for all drain diameters up to 160 mm (DN 150). We also offer customised designs and versions for rounded scuppers on request!
Also available as scupper grating.
Examples
Certifications
Our gravel basket classic for drain and scupper have been tested by TÜV Rheinland LGA Products GmbH.
Technical drawings
Gravel basket classic for drains
Technical data
Gravel basket classic for drains
| H | 77,5 | mm |
| D1 | 160 | |
| D2 | 262 |
Technical drawings
Gravel basket classic for scuppers
Technical data
Gravel basket classic for scuppers
| D | 262 | mm |
| T | 77,5 |
Downloads
Package units
Supplied in cartons, each containing 10 units
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
